Blackmagic Design UltraStudio 4K Mini – 4K Thunderbolt interface, 12G-SDI and HDMI
GTIN: 9338716006087
UltraStudio 4K Mini: Thunderbolt 3 interface with 12G-SDI, HDMI 2.0b, analog connections, XLR mic input and SD card reader, up to 4K DCI 60p with HDR.
Commercial guarantee of durability offered by the producer at no extra cost: 3 years. See the GARAN label
Blackmagic Design UltraStudio 4K Mini – 4K Thunderbolt interface, 12G-SDI and HDMI
UltraStudio 4K Mini is an external Thunderbolt 3 interface for capture and playback up to 4K DCI 60p: it captures 8 and 10-bit HDR up to 4K DCI 60p and 12-bit up to 4K DCI 30p. It combines 12G-SDI, HDMI 2.0b, analog connections, a microphone input and an SD card reader in a small box.
What UltraStudio 4K Mini is for
It is designed for 4K editing and grading with a laptop or compact computer: capture from cameras and recorders, monitor over SDI and HDMI, and mount camera media directly with the SD card reader to start working immediately. With RS-422 control it also handles decks.
Connections
1 x 12G-SDI input, 2 x program and 1 x loop SDI outputs, HDMI 2.0b in and out, component or composite video input, 2 channels of balanced analog audio in and out on 1/4 inch jacks, XLR mic input with 48V phantom power, Black Burst or Tri-Sync reference, RS-422 port, USB-C, UHS-I and UHS-II SD card reader. Internal 100-240V power supply.
Connection and compatibility
It connects to a Thunderbolt 3 port and can charge a laptop with 45 W. It works on Mac, Windows and Linux with the Desktop Video driver, which includes Media Express, Disk Speed Test and the setup utility, and is compatible with the main editing, graphics and streaming software.
System requirements
You need a computer with a Thunderbolt 3 (USB-C) port. Thunderbolt 4 and Thunderbolt 5 ports and the ports of Apple Silicon Macs work too; a USB-C port without Thunderbolt is not enough, and a USB4 port only if it is Thunderbolt 3 compatible. Operating systems: macOS 15 Sequoia, macOS 26 Tahoe or later, 64-bit Windows 10 and Windows 11, Linux. The box includes a QR code to download the software: Desktop Video driver and Media Express and, on Mac and Windows, also Disk Speed Test, LiveKey and the free version of DaVinci Resolve. Blackmagic Design does not state minimum processor, memory or graphics requirements: they depend on the software and the working format. Capturing in Ultra HD and 4K needs a fast enough disk, which you can check with the included Disk Speed Test.
Video formats by connection
12G-SDI (input and outputs): SD, HD up to 1080p60, 2K DCI, Ultra HD and 4K DCI up to 60p on a single cable; 8 and 10-bit YUV 4:2:2 in all formats, 12-bit RGB 4:4:4 up to 4K DCI 30p, 16 audio channels. 2160p50 and 60 need a 12G-SDI cable and device: a 6G-SDI device goes up to 2160p30, a 3G-SDI device up to 1080p60. Fill and key on the two SDI outputs up to 2160p30.
HDMI 2.0b (input and output): SD, HD up to 1080p60, Ultra HD and 4K DCI up to 60p, 4:4:4, 4:2:2 and 4:2:0 at 8, 10 and 12 bit, 8 audio channels. Analog input: composite in SD only (NTSC and PAL), component in SD and HD. On all digital connections: Rec. 601, Rec. 709 and Rec. 2020, HDR with PQ and HLG.
UltraStudio 4K Mini or 4K Extreme 3?
UltraStudio 4K Extreme 3 adds more SDI connections (quad link), 4-channel XLR audio and a PCI Express connection, for high end fixed suites. 4K Mini is the portable choice.
bmdonline.eu is an authorized Blackmagic Design reseller: the official extended warranty is also available for this product.
Technical specifications
Connections
| SDI Video Inputs | 1 |
|---|---|
| SDI Video Outputs | 2 x program out, 1 x loop out. |
| SDI Rates | 270Mb, 1.5G, 3G, 6G, 12G. |
| Analog Video Inputs | Component YUV or Composite NTSC/PAL. Component is switchable between SD and HD. |
| Analog Audio Inputs | 2 channels of professional balanced analog audio with 1/4 inch Jack connectors. |
| Analog Audio Outputs | 2 channels of professional balanced analog audio with 1/4 inc h Jack connectors. |
| SDI Audio Inputs | 16 Channels embedded in SD/HD/2K/UHD/4K. |
| SDI Audio Outputs | 16 Channels embedded in SD/HD/2K/UHD/4K. |
| HDMI 2.0b Video Inputs | 1 1 |
| HDMI Audio Inputs | 8 Channels embedded in SD/HD/UHD/4K. |
| HDMI Audio Outputs | 8 Channels embedded in SD/HD/UHD/4K. |
| Mic Input | 1 x XLR microphone input. 48V Phantom Power switchable via software control. |
| Sync Input | Tri-Sync or Black Burst. |
| Device Control | Sony™ compatible RS-422 deck control port. Serial ports TxRx direction reversible under software control. |
| USB | 1 x USB-C 3.1 Gen 1 (up to 5 Gb/s). |
| SD Card Reader | UHS-I and UHS-II compatible. |
| Computer Interface | Thunderbolt™ 3 (Mac OS, Windows and Linux) with 45W host charging capability. |
Supported Codecs
| AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4. |
Software
| Software Included | DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux. |
|---|---|
| Internal Software Upgrade | Firmware built into software driver. Software driver loads upgrades at system start or via updater software. |
Software Applications
| Other supported applications include: | The Foundry Nuke, Grass Valley Edius, Sony Catalyst Production Suite, Tools On Air Just: Play & Live & In, Softron MovieRecorder & MReplay, Adobe Flash Media Live Encoder, Telestream Wirecast, Resolume Arena, Magix Vegas Pro & Movie Edit Pro Premium, Corel VideoStudio Pro, CyberLink PowerDirector, Vidblaster X & Studio & Broadcast, Uniplay One & CG, CasparCG Server, Magicsoft CG, Xsplit Broadcaster, Imagine Communications Velocity & InfoCaster, DevTek Easy Media Suite, Metus Ingest, Boinx Software MimoLive, Cinegy Capture Pro, vMix Live, Renewed Vision ProPresenter, Ventuz Director, Class X Liveboard & Coral CG, Glookast Capturer, Open Broadcaster Software Studio, Nautilus NEMO3D, Derivative TouchDesigner, Assimilate Scratch, Burst Video Webclip2Go & [REC]Marker, Autodesk Flame, Zoom. These are third party applications and support may vary, check with your software vendor. |
|---|
SDI Video Standards
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL |
|---|---|
| HD Video Standards | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60 |
| 2K Video Standards | 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| 4K Video Standards | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI |
| 3D Video Standards* | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI * Playback only |
| SDI Compliance | SMPTE 259M, SMPTE 274M, SMPTE 296M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2036-1, SMPTE 2048-1, SMPTE 2081-10, SMPTE 2082-10 and SMPTE ST2108-1. |
| SDI Metadata Support | RP 188/SMPTE 12M-2 and closed captioning. |
| Multiple Rate Support | SDI video connections are switchable between SD/HD/2K/UHD and 4K. |
| SDI Audio Sampling | Television standard sample rate of 48 kHz and 24-bit. |
| SDI Video Sampling | 4:2:2, 4:4:4 |
| SDI Color Precision | 8, 10, 12-bit RGB 4:4:4 in 2D modes up to 4Kp30 DCI and 8, 10-bit YUV 4:2:2 in all 2D modes. 8, 10, 12-bit RGB 4:4:4 in 3D modes up to 2Kp60 DCI and 8, 10-bit YUV 4:2:2 in all 3D modes. |
| SDI Color Space | REC 601, REC 709 and REC 2020 |
| HDR Support | HDR static metadata packing, HLG and PQ transfer characteristics. |
HDMI Video Standards
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL |
|---|---|
| HD Video Standards | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| 4K Video Standards | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI |
| 3D Video Standards | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI. |
| HDMI Audio Sampling | Television standard sample rate of 48 kHz and 24-bit. |
| HDMI Video Sampling | 4:4:4, 4:2:2 and 4:2:0 |
| HDMI Color Precision | 8, 10 and 12-bit |
| HDMI Color Space | REC 601, REC 709 and REC 2020 |
| HDR Support | HDR static metadata packing, HLG and PQ transfer characteristics. |
| HDMI Configuration | HDMI 2.0b supports Deep Color and HDR. Automatically configures to connected display. |
| Multiple Rate Support | HDMI video connections are switchable between SD/HD/UHD and 4K. |
| Copy Protection | HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content. |
Processing
| Real Time Effects | DaVinci Resolve, Final Cut Pro X internal effects. Premiere Pro CC Mercury Playback Engine effects. Avid Media Composer internal effects. |
|---|---|
| Colorspace Conversion | Hardware based real time. |
| 3D Processing | Dual stream and frame packed capture and playback. 3D capture supported via HDMI input only. |
| Physical Installation | Requires a computer with a Thunderbolt™ 3 port. Please check support pages to see the full system requirements. |
Operating Systems
| Mac 15.0 Sequoia, Mac 26.0 Tahoe or later. Windows 10, 64-bit. Windows 11. Linux |
Power Requirements
| Power Supply | 1 x Internal 100 - 240V AC |
|---|---|
| Power Usage | 75.3W max |
Environmental Specifications
| Operating Temperature | 5° to 40° C (41° to 104° F) |
|---|---|
| Storage Temperature | -20° to 45° C (-4° to 113° F) |
| Relative Humidity | 0% to 90% non-condensing |
What's Included
| UltraStudio 4K Mini Welcome wallet with QR code for software download |
Warranty
| 3 Year Limited Manufacturer’s Warranty. |
| Product Condition | New |
|---|---|
| Manufacturer | Blackmagic Design |
| manufacturer code | BDLKULSDMINI4K |
| Ean | 9338716006087 |
| Taric Code | 8543709099 |
| Warranty | 3 Year Limited Manufacturer's |
| Product specifications | PrestazioneColore del prodotto* Nero Interno* No Interfaccia host* Thunderbolt Risoluzione acquisizione video 4096 x 2160 Pixel Slot per la scheda di memoria Sì Tipi schede di memoria SD Interfaccia SDI Indicatori LED Sì High Dynamic Range (HDR) supportato Sì Tecnologia High Dynamic Range (HDR) Hybrid Log-Gamma (HLG) VideoFormato video analogico* NTSC, PAL Frequenza massima dei fotogrammi 60 fps Codec video AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4 Modalità video supportate 720p, 1080i, 1080p, 2160p AudioSupporto audio Sì Frequenza di campionamento 48 kHz Formati del fileFormati di compressione video AVCHD, MPEG2 ConnettivitàPorta USB* Sì Connettore USB USB tipo-C Numero di USB 2 Quantità porte HDMI 2 ConnettivitàIngressi HDMI 1 Numero di uscite HDMI 1 Ingressi audio (L,R) 2 Uscita (L, R) audio 2 Uscite per cuffie 1 Quantità di porte BNC 8 Gestione energeticaTipo alimentazione* AC Tensione di ingresso AC 100 - 240 V SoftwareSistema operativo Windows supportato Windows 10 x64, Windows 11 Compatibilità Mac Sì Compatibilità sistema operativo Mac Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura Sistema operativo Linux supportato Sì Software forniti DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux. Condizioni ambientaliIntervallo temperatura di funzionamento 5 - 40 °C Intervallo di temperatura -20 - 45 °C Range di umidità di funzionamento 0 - 90% Dimensioni e pesoLarghezza 210 mm Profondità 177 mm Altezza 46,1 mm Peso 1,2 kg |
| Essential qualities |
|
| Product colour | Black |
| Internal | No |
| Host interface | Thunderbolt |
| Analog signal format system | NTSC, PAL |
| Power supply type | AC |
| Maximum resolution | Ultra HD |
| SDI rate | 12G |
| SD support (PAL/NTSC) | Yes |
| Function | Capture and playback |
| Computer interface | Thunderbolt |
| Video connection type | SDI, HDMI, Analog |
| Independent channels | 1 |
| Channel configuration | Fixed inputs and outputs |
| Format | External unit |
| Reference input | Yes |
| Operating systems | macOS, Windows, Linux |
