SKAARHOJ Inline 10 compact desktop controller with encoders

SKAARHOJ Inline 10

Inline 10 is a compact utility controller with 4 encoders and 6 four-way buttons, particularly suitable for simple colour grading of cameras or adjusting settings on various devices. Its compatibility with the Raw Panel protocol enables custom integrations.

For live events, studio productions or on-location shoots, it provides precise control in a highly portable package, with an intuitive layout for quick adjustments.

Key features

• 4 backlit encoders
• 6 programmable four-way buttons
• OLED displays for labels and feedback
• Raw Panel protocol for custom integrations
• Compact, portable design
• Durable build quality
• Extensive list of supported devices, universal control of multiple third-party devices
• User customization with the Reactor web UI
• 1G Ethernet with PoE
• Designed and made in Denmark

Compatibility

• All devices supported by SKAARHOJ device cores
• Raw Panel protocol applications

In the box

• Inline 10
• 12 V power supply (PHIHONG PSA15R-120P, 12 V / 1.25 A, 1.5 m cable, plug for the destination country)
• Getting Started Guide

Specifications

• Buttons: 6 elastomer four-way buttons with display
• Encoders: 4
• OLED: 6 tiles 64x32 pixels, 4 tiles 112x32 pixels
• Network: 1G Ethernet with Power over Ethernet (PoE IEEE 802.3af/at)
• Power: PoE (IEEE 802.3af/at) or 12 V DC jack 5.5 x 2.1 mm, centre positive
• Service port: Micro USB for manual IP setting
• Platform: Blue Pill Inside (Reactor, device cores, skaarOS Linux), full Reactor and Device Core licenses included
• Footprint (technical drawing): 130 x 94 mm
• Weight: 332 g
• Recommended (not included): Cat 6 S/FTP Ethernet cable or better
